Portable and rack-mount instruments: the DAS acoustic sensing instrument reaches 110 km at 5.8 kg, while the BOTDA Brillouin analyzer reaches 104 km with ±1 °C and ±20 με accuracy. Fibre in, results out — no external optics to align.
Portable and rack-mount instruments: the DAS acoustic sensing instrument reaches 110 km at 5.8 kg, while the BOTDA Brillouin analyzer reaches 104 km with ±1 °C and ±20 με accuracy. Fibre in, results out — no external optics to align.
DAS-22-80KM
DAS-22-80KM is a portable distributed acoustic sensing instrument with up to 110 km single-channel range, 3–26 m spatial resolution, 0.01 Hz–100 kHz frequency response, 5.8 kg weight and 33–55 W power consumption, supporting polarization, spatial and frequency diversity reception with coherent-fading suppression.
View specifications
BOTDA-002
BOTDA-002 is a Brillouin optical time-domain analysis instrument for distributed temperature and strain monitoring: 100 m to 104 km sensing fibre per channel, ±1 °C temperature accuracy, ±20 με strain accuracy, spatial resolution from 0.8 m at 25 km range to 3.2–26 m at 100 km range, both BOTDA and BOTDR operation, real-time dual-channel acquisition, in a 19-inch 2U chassis.
View specifications
DAS-10-50KM
DAS-10-50KM is the single-channel entry configuration: 50 km per channel, 3–26 m spatial resolution, 0.01 Hz–100 kHz bandwidth, 5.8 kg and 33–55 W. Frequency-diversity reception suppresses coherent fading, making it suitable for continuous monitoring of one short-to-medium fibre link.
View specifications
DAS-21-55KM
DAS-21-55KM is the two-channel workhorse: 55 km per channel with polarization plus frequency diversity reception, 3–26 m spatial resolution, 0.01 Hz–100 kHz bandwidth, 5.8 kg and 33–55 W. Two independent fibres are monitored simultaneously.
View specifications
DAS-40-50KM
DAS-40-50KM is the four-channel model: four independent fibres monitored at once, up to 50 km per channel, 3–26 m spatial resolution, 0.01 Hz–100 kHz bandwidth, 5.8 kg and 33–55 W — built for centralised monitoring of several sites (four pipeline sections, four perimeters, four well pads).
View specificationsChoose an instrument for field deployment with results out of the box; choose an acquisition card if you are building your own system. Send us your range and fibre conditions and we will assess the link.
